Fisher EZH User Manual

Europe, Middle East and Africa Document Only
Types EZH and EZHSO
26
Parts List

Key Description
1 Body
2 Seat
3 Cage
4* Anti-friction ring
5 Actuator lower casing
6 Cap screws
7* O-ring
8* Anti-friction ring
9* O-ring
10 Pipe Plug
11 Actuator upper casing
13 Spring
14 Sleeve
15* O-ring
16 Screw
17* O-ring
18 Inlet plate
19 Outlet plate
20* Diaphragm
21 Screw
22 Washer
23 Nut
24 Screw
25 Intermediate ange
27 Sleeve adaptor
28* O-ring
29* O-ring
30* Disk holder assembly
31 Disk retainer
32 Lock washer
33 Socket head cap screw
34* O-ring
35 Bracket
38 Travel indicator plug
44 Adjusting screw cap
61 Sleeve guide
62* O-ring
63* O-ring
64* O-ring
66 Screw
67* Washer
68 Smart screw
69* O-ring
70 Cap
71* O-ring
72 Lock washer
73 Upper spring seat
74 Socket head cap screw
75* O-ring
77 Screw
78 Cage
82 Lower spring seat
83 Ball bearings
138 Indicator cover
139 Stem
140 Indicator bushing
141 Fitting
142* O-ring
143* O-ring
144 Spring collet
145 Retaining ring
192 Nameplate

Key Description
146 Protective cap
147 Stem
148 Upper spring axe
149 Lower spring axe
150* Anti-friction ring
151 Stem nut
152 Hex nut
153* O-ring
154 Hex socket cap screw
155 Stem nut
156 Upper spring seat adapter
157* Anti-friction ring
158* O-ring
159 Check valve
193 Washer
Type EZH OS2 Release Relay (Figure 20)
Key Description
45* O-ring
46 Valve plug
47 Body
48 Fitting
49* O-ring
50 Screw
51 Screw
52 Seat
53* Bypass
54* Guide ring
55 Spring
56* O-ring
57 Cover
Type EZH "X Body" (Figure 21)
Key Description
1 Screw
2* O-ring
3* O-ring
4 Bottom
5 Seat
6 O-ring
Type EZH Silencer (Figure 22)
Key Description
161 Attenuation Module
2 Seat
34* O-ring

Key Description
159 Check valve
160 Male tube connector
* Spare parts kit
