Technical data11
11.4 FLIR K2
P/N: 73701-0101
Rev.: 39875
General description
The FLIR K2 is a robust and reliable infrared camera designed to perform under extremely severe condi-
tions. The FLIR K2 has an intuitive interface with a design that makes it easy to control even with a gloved
hand.
Benefits:
• Robust and reliable: The FLIR K2 is designed to meet tough operating conditions. It can withstand a
drop from 2 m (6.5 ft.), is water resistant to IP67, and is fully operational up to 55°C (135°F), and op-
erational up to +85°C (+185°F) for 15 minutes, +150°C (+302°F) for 10 minutes, and +260°C (+500°
F) for 3 minutes.
• Innovative: The FLIR K2 utilizes our patented technology MSX, where a thermal sensor is combined
with a visual camera sensor to give detailed image information in many user situations.
• Easy-to-use: Easily used in a gloved professional hand. An intuitive and simple user interface allows
you to focus on the job. The FLIR K2 can be controlled by just one large button on top of the unit.
Typical applications:
• Heat detection.
• Search and rescue.
• Final extinction.
• Back-up camera.
• Scanning camera.
• Fire attack.
Imaging and optical data
IR resolution 160 × 120 pixels
Thermal sensitivity/NETD < 100 mK @ +30°C (+86°F)
Field of view (FOV)
47° × 35°
Depth of field 0.1 m (0.33 ft.), infinity
Focal length 1.9 mm (0.075 in.)
Spatial resolution (IFOV)
6.22 mrad
F-number 1.1
Image frequency 9 Hz
Focus Fixed
Detector data
Detector type Focal plane array, uncooled microbolometer
Spectral range
7.5–13 µm
Pitch 12 μm
Visual camera
Built-in digital camera 640 × 480 pixels
Digital camera, FOV 73° × 61°, adapts to the IR lens
Sensitivity Minimum 10 lux
#T559972; r. AG/39882/39882; en-US
28
