1.
To
release
the
head
restraint,
grasp
the
pull
strap
and
pull
toward
you
(approximately
one
inch),
which
will
allow
you
to
insert
your
hand
at
the
bottom
of
the
head
restraint,
as
shown
in
Figure
3.
[SR15125(
X)05/95]
17-1/2
pica
art:0090173-A
Figure
3:
Releasing
the
child
safety
seat
head
restraint
File:03unsrx.ex
Update:Thu Feb 29 09:02:31 1996
39
