Replacing front side marker bulbs
1. Open the hood.
2. Remove two screws from the
lamp assembly.
3. Disengage lamp assembly (it has
a snap fit).
4. Disconnect the electrical
connector from the bulb by pulling
rearward.
5. Rotate bulb socket
counterclockwise about
1
⁄
4
turn and
remove from lamp assembly.
6. Carefully pull bulb straight out of
socket and push in the new bulb.
7. Insert the bulb into the parking
lamp assembly. When the grooves in
the plastic base are aligned, push
the bulb into the lamp assembly
until the plastic base contacts the rear of the lamp assembly and turn to
lock.
8. Connect the electrical connector into the rear of the plastic base until
it “snaps.”
9. Align the lamp studs with the plastic grommets on the vehicle and
push to snap in place.
10. Install two screws on lamp assembly.
Maintenance and care
199
