Temperature control knob
Controls the temperature of the
airflow inside the vehicle. On
heater-only systems, the air cannot
be cooled below the outside
temperature.
Mode selector control
Controls the direction of the airflow
to the inside of the vehicle.
•
(Panel)-Distributes outside air through the instrument panel
registers.
• (Panel and floor)-Distributes outside air through the instrument
panel registers and the floor ducts.
• OFF-Outside air is shut out and the fan will not operate.
•
(Floor)-Allows for maximum heating. Distributes outside air
through the floor ducts.
• (Floor and defrost)-Distributes outside air through the floor
ducts and the windshield defroster ducts.
•
(Defrost)-Distributes outside air through the windshield
defroster ducts. It can be used to clear ice or fog from the windshield.
Operating tips
• In humid weather, select before driving. This will reduce fogging
on your windshield. After a few minutes, select any desired position.
• To reduce humidity buildup inside the vehicle, don’t drive with the
climate control system in the OFF position.
• Don’t put objects under the front seat that will interfere with the
airflow to the rear seats (if equipped).
OFF
Controls and features
20
