GEM Active Command Index
GEM Active Command Index
OnOB-, OnOBG
HALLPWR Center Axle Hall Power Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
IGN_A Ignition Switch -ACCY Position NO, YES
IGN_KEY Ignition Key In / Out OUT, IN
IGN_O/L Ignition Switch -OFF/Lock Position NO, YES
IGN_R Ignition Switch -RUN Position NO, YES
IGN_S Ignition Switch -START Position NO, YES
INTLMP Illuminated Entry Relay Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
LRDR_SW Left Rear Door Ajar Switch CLOSED, AJAR
MECHLCK Mechanical Lock Output Status Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
MTR_CCW Trans. Xfer Counter Cw Motor
Output
Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
MTR_CW Trans. Xfer Clockwise Motor Output Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
NTRL_SW Neutral Safety Switch Input notNTL, NTRL
OTD_SW One Touch Down Switch OFF, DOWN
P_DOOR Passenger Door Ajar Switch CLOSED, AJAR
PARK_SW Parking Sw OFF, ON
PLATE_A Trans. Xfer Case Contact Plate A OPEN, CLOSED
PLATE_B Trans. Xfer Case Contact Plate B OPEN, CLOSED
PLATE_C Trans. Xfer Case Contact Plate C OPEN, CLOSED
PLATE_D Trans. Xfer Case Contact Plate D OPEN, CLOSED
PLATEPW Trans. Xfer Case Contact Plt Pul
Wid
Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
PWM_DC1 PWM Duty Cycle #1 %
PWR_RLY Power Relay Feedback Input OFF, ON
R_WP_DN Rear Wiper Down Output Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
R_WP_MD Rear Wiper Mode Switch WASH, OPEN, INVLD, INTVL1, INTVL2
R_WP_PK Rear Wiper Park Sense notPRK, PARKED
R_WP_UP Rear Wiper Up Output Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
RDEF_SW Rear Defrost Switch OFF, ON
RDEFRLY Rear Defrost Relay Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
RRDR_SW Right Rear Door Ajar Switch CLOSED, AJAR
RWASHSW Rear Washer Switch Position Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
SBLTLMP Seat Belt Lamp Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
SPEEDWP Speed Dependent Wiper Function notACT, ACTIVE
TRA_FSP Trans. Transfer Case Front Speed KPH
TRA_RSP Trans. Transfer Case Rear Speed KPH
VBAT Battery Voltage VDC
VSS Vehicle Speed KPH
VSS Vehicle Speed Low Resolution
(Mph)
one count per bit MPH
WASH_SW Washer Pump Switch OFF, ON
WASHRLY Washer Pump Relay Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
WFL_LMP Washer Fluid Lamp Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
WFLUID Washer Fluid Level LOW, OK
WPHISP Wiper Two Speed Relay Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
WPMODE Wiper Control Mode Select WASH, OPEN, OFF, INTVL1, INTVL2, INTVL3, INTVL4, INTVL5, INTVL6, INTVL7, LOW, HIGH, ?
WPPK_PK Wiper Park-To-Park Time mS
WPPRKSW Windshield Wiper Park Sense notPRK, PARKED
WPRUN Wiper Run Relay Driver State Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G,
OnOB-, OnOBG
Active Command Display Action
4WD TRANS CASE & INDICATOR CONTROL 4WDMODE L OFF, ON
4WD TRANSFER CASE CONTROL CW/CCW OFF, ON
4WD TRANSFER CASE CONTROL CW/CCW OFF, ON
To Next Page
