Page 43
2008K
2
Preventive Maintenance Procedures
P/N 508138 Rev. J
3.27 BLOOD PRESSURE MODULE
Note: There are seven types of blood pressure modules that can be connected
to the 2008K
2
. Since each module type has different test criteria and the
2008K
2
is unable to detect which module is connected, disregard the displayed
Pass/Fail results if present and use the appropriate table to determine pass or
fail.
Test the blood pressure module (See Figure 3, pg. 9), as follows:
Place the machine in Service Mode.
Select
1
the Test BP Module screen key and the screen will change.
INFLATION SPEED TEST
From the Test BP Module screen, select
1
the Inflation Speed button.
1. Connect the 10 foot blood pressure tubing from the module to the 700cc
port on the Dummy Cuff. Ensure the tubing fits snugly on the ports.
2. Press the [CONFIRM] key. The screen will change and the test will start.
3. The blood pressure module will pressurize the Dummy Cuff and report the
time. When the test is complete, use the table below to verify that the Time
to 250 value is within range dependent upon the module type installed.
Module Type Time to 250
M400 ≤ 7.3 seconds
M2000, M2600 or M3600 ≤ 10.0 seconds
TM-2910 or TM-2915 ≤ 10.0 seconds
SunTech ≤ 11.0 seconds
4. Press the [CONFIRM] key.
1
Refer to Section 1.3 on the use of screen buttons.
