DOOR REMOVAL INSTRUCTIONS
DOOR REMOVAL INSTRUCTIONS:
Ifitisnecessarytomovetherefrigeratorthroughnarrowdoorways,followthesestepsto
removethedoors.
Before you start:
1 Makesuretheelectricalpowercordisunpluggedfromthewalloutlet.
2 Removeanyfoodfromthedoorshelves.
3 Closethedoors.
To remove the hinge cover: (some models)
1 Removethethreescrewsfromthecoveroverthetopdoorhinges.
2 Pullthecoverforwardaboutahalfinchandliftitoff.
To remove the refrigerator door:
1 Removetophingecoverscrewonrefrigeratordoorandremovecover.(somemodels)
2 Tracelightlyaroundthedoor’stophingewithapencil.Thismakesreinstallation
easier.
3 Removethetwoscrewsfromthetophinge.Liftthedooroffofthebottomhingeand
setitaside.
4 Removethethreebottomhingescrewsandhinge,ifnecessary.
To remove the freezer door:
1 Detachthemulti-wirecableconnectorlocatedabovethetophinge.Graspbothsides
oftheconnectorrmlyandpullapart.
2 Removetophingecoverscrewonfreezerdoorandremovecover.(somemodels)
3 Tracelightlyaroundthedoor’stophingewithapencil.Thismakesreinstallation
easier.
4 Detachthewatertubefromtheconnectorlocatedbelowthefreezerdoor.The
connectorreleaseswhenyoupressitsoutersleeveinward.
5 Removethescrewsfromthetophingeandpullthemulti-wirecablethroughit.
6 Liftthedooroffofthebottomhinge.Laythedooronitssidetoavoiddamagetothe
Removethethreebottomhingescrewsandhinge,ifnecessary.
Toreinstalltherefrigeratorandfreezerdoors,reversetheabovesteps.
Adjustable
Wrench
Socket
Wrench Set
OR
Phillips head
and
Flat Head
Screw Driver
™
Tools Necessary:
3/8”
Fixed
Wrench
TopHinge
CoverScrew
Bottom
Hinge
Screw
T o p
Hinge
Screw
TO DISCONNECT
1.Pressouterringagainstface
offitting
2.Pullto
removetube
TO CONNECT
Inserttubeand
pushuntilmarktouchesfaceoffitting
or
7/16”
and
