Fronius Primo User Manual

27
EN
Serial Number Sticker for Customer Use
Serial number
sticker for cus-
tomer use
The serial number of the inverter is located
on the rating plate on the bottom of the in-
verter.
Depending on the installation position of the
inverter, the serial number can be difficult to
access or read, e.g. if the inverter has been
installed in a dark or shaded area.
Two serial number stickers are enclosed
with the inverter's Installation Instructions:
* 57 x 20 mm
** 67 x 20 mm
These can be affixed by the customer in a
visible location of his choosing, e.g. on the
front of the inverter or on the Operating Ins-
tructions.
Application example:
Serial number sticker on the Operating Ins-
tructions or on the front of the inverter
For Australia only:
Affix the DRM Australia sticker in the Data-
manager area.
Serial No. on rating plate
?
+
Fronius Inverter
Installation
*
**
DRM‘s for
Australia
I9
4/8
I7
2/6
I5 IO3
CL/0
IO1 GND GND D-
3/7
I8
1/5
I6
I4
RG/0
IO2 12V+12V+IO0
D+
DRM‘s for
Australia
I9
4/8
I7
2/6
I5 IO3
CL/0
IO1 GND GND D-
3/7
I8
1/5
I6
I4
RG/0
IO2 12 V+ 12 V+ IO0
D+
Fronius Inverter
Operating
Instructions
* Serial Number Sticker for Customer Use, 57 x 20 mm
** DRMs for Australia for Customer Use, 67 x 20 mm
***
Application example
DRM‘s for
Australia
I9
4/8
I7
2/6
I5 IO3
CL/0
IO1 GND GND D-
3/7
I8
1/5
I6
I4
RG/0
IO2 12 V+ 12 V+ IO0
D+
2
only Australia
1
