S5860-48SC
NOTE: S5860 series switches have dust plugs delivered with them. Keep the dust plugs
properly and use them to protect idle optical ports.
Hardware Overview
Front/Back Panel Ports
S5860-20SQ
MGMT
CONSOLE
25G
STATUSPWR1 PWR2 FAN MGMT ID
1 2
3 4
21
43 65 87 109 1211 1413 1615 1817 2019 2221 2423
40G Breakout
25
26
S5860-20SQ
40G
FUNC
USB CONSOLE QSFP+
MGMT
SFP+ SFP28
Grounding Cable x1Power Cord x2 Mounting Bracket x2 M4 Screw x14
M6 Screw x8 M6 Nut x8 Inner Rail x2Slide Rail x2
To Next Page
