8. Additional charge calculation
8-1. Model: AOYG36KBTA5
Refrigerant type R32
Refrigerant amount g 2,500
Refrigerant charge
Total pipe length m 40 or less 50 60 70 75 (Max.)
20 g/m
Additional charge amount g 0 200 400 600 700
- 536 -
8-1. Model: AOYG36KBTA5
8. Additional charge calculation
OUTDOOR UNIT
AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
