INDOOR UNIT ACCESSORIES
Q’ty
2
2
4
4
1
1
2
2
1
1
Name and Shape
Coupler heat
insulation
Tapping Screw
(flush heads)
Special nut A
(large flange)
Special nut B
(small flange)
Template
Binder
(small)
Blower cover insulation
Hook wire
Remote
controller
Remote controller cord
Application
For indoor side pipe joint
For installing the remote
controller
For installing indoor unit
For installing indoor unit
For ceiling hole cutting
For fixing the remote
controller cord
For discharged air
For installing intake grille
For connecting the remote
controller
STANDARD
ACCESSORIES
2005.12.26
42
42
44
Table of Contents
Table of Contents
1
Air Conditioner
1
Specifications
2
Dimensions
4
Refrigerant System Diagram
8
Circuit Diagram
10
Indoor Pcb Circuit Diagram
14
Outdoor Pcb Circuit Diagram
16
Checking Drainage
22
Self-Diagnosis
22
Remote Controller Display
22
Error Contents
22
Error Contents
23
Disassembly Illustration
24
Parts List
39
Standard Accessories
43
Standard Parts
44
Connection Pipe Requirement
44
