1. Specifications
Type Inverter heat pump
Model name AOYG07KPCA AOYG09KPCA AOYG12KPCA
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Starting current A 3.2 3.8 5.6
Fan
Airflow rate
Cooling
m
3
/h
1,650 1,650 1,700
Heating 1,450 1,450 1,470
Type × Q'ty Propeller fan × 1
Motor output W 23
Sound pressure level *1
Cooling
dB (A)
45 47 49
Heating 46 47 51
Sound power level
Cooling
dB (A)
57 59 62
Heating 58 59 62
Heat exchanger type
Dimensions
(H × W × D)
mm
504 × 650 × 18.2 504 × 630 × 36.4
Fin pitch 1.3
Rows × Stages 1 × 24 2 × 24
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment PC Fin
Compressor
Type × Q'ty DC Rotary × 1
Motor output W 850
Refrigerant
Type (Global warming potential) R32 (675)
Charge g 550 590
Refrigerant oil
Type POE
Amount
cm
3
240
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
541 × 663 × 290
Gross 596 × 798 × 369
Weight
Net
kg
23 25
Gross 25 27
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (1/4)
Gas Ø 9.52 (3/8)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
Drain hose
Material PP
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
