Fujitsu ASYG07KPCA User Manual

4. Refrigerant circuit
4-1. Models: AOYG07KPCA, AOYG09KPCA, and AOYG12KPCA
Strainer
Strainer
3-way
valve
2-way
valve
4-way valve
Expansion valve
Heat exchanger
Heat exchanger
(INDOOR)
(OUTDOOR)
Compressor
Cooling
Heating
Th
D
Th
R
Th
PI
Th
O
Th
HO
: Thermistor (Discharge temperature)
: Thermistor (Outdoor temperature)
: Thermistor (Heat exchanger out temperature)
Th
D
Th
O
Th
HO
: Thermistor (Room temperature)
: Thermistor (Pipe temperature)
Th
R
Th
PI
Muffler
- 31 -
4-1. Models: AOYG07KPCA, AOYG09KPCA, and AOYG12KPCA 4. Refrigerant circuit
OUTDOOR UNIT AOYG07-12KPCA OUTDOOR UNIT AOYG07-12KPCA
