Models: ASYG07LMCA, ASYG09LMCA, ASYG12LMCA,
ASYG14LMCA, ASYG07LMCE, ASYG09LMCE, ASYG12LMCE
and ASYG14LMCE
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Cloth tape 1
Installation manual 1
Tapping screw (large),
M4 × 25 mm
5
Wall hook bracket 1
Tapping screw (small),
M3 × 12 mm
2
Remote controller 1 Air cleaning filter 2
Battery 2 Filter holder 2
Remote controller
holder
1
Seal A
• It is necessary when
using 14 model.
• It is used when the
diameter of gas pipe
is Ø12.70 or more.
1
- 259 -
MULTI TYPE
5, 6 ROOMS TYPE
To Next Page
