6. Capacity table
6-1. Combinations
¢
Model: AOYG45LBLA6

Cooling
Combination of indoor unit Rated capacity for each indoor unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
EER
(W/W)Room
Total
Room
Min.
Rated
Max. Min.
Rated
Max.
1 2 3 4 5 6 1 2 3 4 5 6
12 24 — — — — 36 3.50 7.00 — — — — 3.5 10.5 11.5 0.8 3.06 3.32 3.43
14 24 — — — — 38 4.00 7.00 — — — — 3.5 11.0 12.1 0.8 3.28 3.70 3.35
18 18 — — — — 36 5.00 5.00 — — — — 3.5 10.0 11.5 0.8 2.92 3.32 3.42
18 24 — — — — 42 5.00 7.00 — — — — 3.5 12.0 13.4 0.8 3.75 4.46 3.20
24 24 — — — — 48 6.25 6.25 — — — — 3.5 12.5 14.0 0.8 4.01 4.84 3.12
7 7 24 — — — 38 2.00 2.00 7.00 — — — 3.5 11.0 12.1 0.8 3.19 3.70 3.45
7 9 18 — — — 34 2.00 2.50 5.00 — — — 3.5 9.5 10.8 0.8 2.55 2.93 3.73
7 9 24 — — — 40 2.00 2.50 7.00 — — — 3.5 11.5 12.7 0.8 3.41 4.08 3.37
7 12 18 — — — 37 2.00 3.50 5.00 — — — 3.5 10.5 11.8 0.8 3.02 3.51 3.48
7 12 24 — — — 43 2.00 3.50 6.90 — — — 3.5 12.4 13.7 0.8 3.82 4.65 3.25
7 14 14 — — — 35 2.00 4.00 4.00 — — — 3.5 10.0 11.1 0.8 2.81 3.13 3.56
7 14 18 — — — 39 2.00 4.00 5.00 — — — 3.5 11.0 12.4 0.8 3.23 3.89 3.41
7 14 24 — — — 45 1.94 3.89 6.67 — — — 3.5 12.5 14.0 0.8 3.89 4.84 3.21
7 18 18 — — — 43 2.00 5.00 5.00 — — — 3.5 12.0 13.7 0.8 3.69 4.65 3.25
7 18 24 — — — 49 1.79 4.59 6.12 — — — 3.5 12.5 14.0 0.8 3.87 4.84 3.23
7 24 24 — — — 55 1.60 5.45 5.45 — — — 3.5 12.5 14.0 0.8 3.83 4.84 3.26
9 9 18 — — — 36 2.50 2.50 5.00 — — — 3.5 10.0 11.5 0.8 2.84 3.32 3.52
9 9 24 — — — 42 2.50 2.50 7.00 — — — 3.5 12.0 13.4 0.8 3.65 4.46 3.29
9 12 14 — — — 35 2.50 3.50 4.00 — — — 3.5 10.0 11.1 0.8 2.81 3.13 3.56
9 12 18 — — — 39 2.50 3.50 5.00 — — — 3.5 11.0 12.4 0.8 3.23 3.89 3.41
9 12 24 — — — 45 2.50 3.33 6.67 — — — 3.5 12.5 14.0 0.8 3.89 4.84 3.21
9 14 14 — — — 37 2.50 4.00 4.00 — — — 3.5 10.5 11.8 0.8 3.02 3.51 3.48
9 14 18 — — — 41 2.50 4.00 5.00 — — — 3.5 11.5 13.0 0.8 3.45 4.27 3.33
9 14 24 — — — 47 2.40 3.72 6.38 — — — 3.5 12.5 14.0 0.8 3.88 4.84 3.22
9 18 18 — — — 45 2.50 5.00 5.00 — — — 3.5 12.5 14.0 0.8 3.89 4.84 3.21
9 18 24 — — — 51 2.21 4.41 5.88 — — — 3.5 12.5 14.0 0.8 3.86 4.84 3.24
9 24 24 — — — 57 1.98 5.26 5.26 — — — 3.5 12.5 14.0 0.8 3.82 4.84 3.27
12 12 12 — — — 36 3.50 3.50 3.50 — — — 3.5 10.5 11.5 0.8 2.98 3.32 3.52
12 12 14 — — — 38 3.50 3.50 4.00 — — — 3.5 11.0 12.1 0.8 3.19 3.70 3.45
12 12 18 — — — 42 3.50 3.50 5.00 — — — 3.5 12.0 13.4 0.8 3.65 4.46 3.29
12 12 24 — — — 48 3.13 3.13 6.24 — — — 3.5 12.5 14.0 0.8 3.87 4.84 3.23
12 14 14 — — — 40 3.50 4.00 4.00 — — — 3.5 11.5 12.7 0.8 3.41 4.08 3.37
12 14 18 — — — 44 3.50 4.00 5.00 — — — 3.5 12.5 14.0 0.8 3.89 4.84 3.21
12 14 24 — — — 50 3.00 3.50 6.00 — — — 3.5 12.5 14.0 0.8 3.86 4.84 3.24
12 18 18 — — — 48 3.12 4.69 4.69 — — — 3.5 12.5 14.0 0.8 3.87 4.84 3.23
12 18 24 — — — 54 2.78 4.17 5.55 — — — 3.5 12.5 14.0 0.8 3.85 4.84 3.25
12 24 24 — — — 60 2.50 5.00 5.00 — — — 3.5 12.5 14.0 0.8 3.81 4.84 3.28
14 14 14 — — — 42 4.00 4.00 4.00 — — — 3.5 12.0 13.4 0.8 3.65 4.46 3.29
14 14 18 — — — 46 3.80 3.80 4.90 — — — 3.5 12.5 14.0 0.8 3.88 4.84 3.22
14 14 24 — — — 52 3.37 3.37 5.76 — — — 3.5 12.5 14.0 0.8 3.85 4.84 3.25
14 18 18 — — — 50 3.50 4.50 4.50 — — — 3.5 12.5 14.0 0.8 3.86 4.84 3.24
14 18 24 — — — 56 3.13 4.02 5.35 — — — 3.5 12.5 14.0 0.8 3.83 4.84 3.26
14 24 24 — — — 62 2.82 4.84 4.84 — — — 3.5 12.5 14.0 0.8 3.80 4.84 3.29
18 18 18 — — — 54 4.17 4.17 4.17 — — — 3.5 12.5 14.0 0.8 3.85 4.84 3.25
18 18 24 — — — 60 3.75 3.75 5.00 — — — 3.5 12.5 14.0 0.8 3.81 4.84 3.28
7 7 7 14 — — 35 2.00 2.00 2.00 4.00 — — 3.5 10.0 11.1 0.8 2.50 3.13 4.00
7 7 7 18 — — 39 2.00 2.00 2.00 5.00 — — 3.5 11.0 12.4 0.8 3.06 3.89 3.59
7 7 7 24 — — 45 1.94 1.94 1.94 6.68 — — 3.5 12.5 14.0 0.8 3.77 4.84 3.32
7 7 9 12 — — 35 2.00 2.00 2.50 3.50 — — 3.5 10.0 11.1 0.8 2.50 3.13 4.00
7 7 9 14 — — 37 2.00 2.00 2.50 4.00 — — 3.5 10.5 11.8 0.8 2.79 3.51 3.76
7 7 9 18 — — 41 2.00 2.00 2.50 5.00 — — 3.5 11.5 13.0 0.8 3.33 4.27 3.45
7 7 9 24 — — 47 1.86 1.86 2.39 6.39 — — 3.5 12.5 14.0 0.8 3.75 4.84 3.33
7 7 12 12 — — 38 2.00 2.00 3.50 3.50 — — 3.5 11.0 12.1 0.8 3.00 3.70 3.67
7 7 12 14 — — 40 2.00 2.00 3.50 4.00 — — 3.5 11.5 12.7 0.8 3.27 4.08 3.52
7 7 12 18 — — 44 2.00 2.00 3.50 5.00 — — 3.5 12.5 14.0 0.8 3.78 4.84 3.31
7 7 12 24 — — 50 1.75 1.75 3.00 6.00 — — 3.5 12.5 14.0 0.8 3.74 4.84 3.34
7 7 14 14 — — 42 2.00 2.00 4.00 4.00 — — 3.5 12.0 13.4 0.8 3.51 4.46 3.42
7 7 14 18 — — 46 1.90 1.90 3.80 4.90 — — 3.5 12.5 14.0 0.8 3.77 4.84 3.32
7 7 14 24 — — 52 1.68 1.68 3.37 5.77 — — 3.5 12.5 14.0 0.8 3.73 4.84 3.35
7 7 18 18 — — 50 1.75 1.75 4.50 4.50 — — 3.5 12.5 14.0 0.8 3.74 4.84 3.34
7 7 18 24 — — 56 1.56 1.56 4.02 5.36 — — 3.5 12.5 14.0 0.8 3.70 4.84 3.38
7 7 24 24 — — 62 1.41 1.41 4.84 4.84 — — 3.5 12.5 14.0 0.8 3.67 4.84 3.41
7 9 9 9 — — 34 2.00 2.50 2.50 2.50 — — 3.5 9.5 10.8 0.8 2.31 2.93 4.11
7 9 9 12 — — 37 2.00 2.50 2.50 3.50 — — 3.5 10.5 11.8 0.8 2.79 3.51 3.76
7 9 9 14 — — 39 2.00 2.50 2.50 4.00 — — 3.5 11.0 12.4 0.8 3.06 3.89 3.59
7 9 9 18 — — 43 2.00 2.50 2.50 5.00 — — 3.5 12.0 13.7 0.8 3.57 4.65 3.36
7 9 9 24 — — 49 1.79 2.30 2.30 6.11 — — 3.5 12.5 14.0 0.8 3.74 4.84 3.34
7 9 12 12 — — 40 2.00 2.50 3.50 3.50 — — 3.5 11.5 12.7 0.8 3.27 4.08 3.52
7 9 12 14 — — 42 2.00 2.50 3.50 4.00 — — 3.5 12.0 13.4 0.8 3.51 4.46 3.42
7 9 12 18 — — 46 1.90 2.45 3.26 4.89 — — 3.5 12.5 14.0 0.8 3.77 4.84 3.32
7 9 12 24 — — 52 1.68 2.16 2.88 5.78 — — 3.5 12.5 14.0 0.8 3.73 4.84 3.35
7 9 14 14 — — 44 2.00 2.50 4.00 4.00 — — 3.5 12.5 14.0 0.8 3.78 4.84 3.31
7 9 14 18 — — 48 1.82 2.34 3.65 4.69 — — 3.5 12.5 14.0 0.8 3.75 4.84 3.33
7 9 14 24 — — 54 1.62 2.08 3.24 5.56 — — 3.5 12.5 14.0 0.8 3.71 4.84 3.37
- 353 -
OUTDOOR UNIT AOYG45LBLA6
