2. MODEL SELECTION
FLOOR TYPE6-1-5.
MODEL : AG
 
G09LVCA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3 .18 2.40 3.43 2.47
0.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3.18 2.40 3.43 2.47
5.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3.18 2.40 3.43 2.47
10.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3.18 2.40 3.43 2.47
15.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3.18 2.40 3.43 2.47
20.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3 .18 2.40 3.23 2.42
25.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 3.07 2.32 3.15 2.35
30.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.92 2.29 2.96 2.25 3.04 2.30
35.0 2.11 1.62 2.32 1.80 2.49 1.94 2.64 2.09 2.78 2.21 2.89 2.21 2.94 2.26
40.0 2.11 1.62 2.32 1.80 2.42 1.93 2.49 2.07 2.62 2.11 2.72 2.10 2.77 2.16
46.0 2.11 1.62 2.06 1.66 2.28 1.85 2.34 1.97 2.47 2.00 2.56 1.98 2.61 2.06
MODEL : AG
 
G12LVCA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.23 2.99 4.58 3.09
0.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.23 2.99 4.58 3.09
5.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.23 2.99 4.58 3.09
10.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.23 2.99 4.58 3.09
15.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.23 2.99 4.58 3.09
20.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.23 2.99 4.30 3.03
25.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 4.09 2.89 4.20 2.94
30.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.89 2.82 3.95 2.81 4.06 2.88
35.0 2.82 1.90 3.10 2.24 3.32 2.42 3.52 2.60 3.71 2.72 3.85 2.75 3.92 2.84
40.0 2.82 1.90 3.10 2.24 3.23 2.40 3.32 2.56 3.50 2.60 3.63 2.61 3.70 2.72
46.0 2.82 1.90 2.75 2.04 3.03 2.31 3.12 2.47 3.29 2.47 3.41 2.47 3.48 2.59
MODEL : AG
 
G14LVCA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
0.0 3.28 2.15 3.61 2.53 3.86 2.74 4 .10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
5.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
10.0 3.28 2 .15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
15.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.33 3.49
20.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.93 3.38 5.01 3.43
25.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.77 3.27 4.89 3.33
30.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.53 3.19 4.60 3 .18 4.73 3.26
35.0 3.28 2.15 3.61 2.53 3.86 2.74 4.10 2.95 4.32 3.09 4.48 3.11 4.57 3.22
40.0 3.28 2.15 3.61 2.53 3.76 2.73 3.87 2.90 4.07 2.95 4.23 2.96 4.31 3.08
46.0 3.28 2.15 3.20 2.31 3.53 2.62 3.64 2.80 3.83 2.80 3.97 2.80 4.05 2.94
COOLING CAPACITY
TC : Total Capacity kW.
SHC : Sensible Heat Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 27) -
