2. MODEL SELECTION
HEATING CAPACITY6-2.
COMPACT CASSETTE TYPE6-2-1.
MODEL : AU
 
G07LVLA
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.87 1.73 1.59 1.45 1.26
-10.0 -11.0 2.09 1.93 1.78 1.62 1.41
-5.0 -7.0 2.33 2.15 1.98 1.80 1.57
0.0 -2.0 2.54 2.35 2.16 1.97 1.72
5.0 3.0 2.73 2.52 2.32 2.11 1.84
7.0 6.0 2.79 2.58 2.37 2.16 1.88
10.0 8.0 2.79 2.58 2.37 2.16 1.88
15.0 10.0 2.79 2.58 2.37 2.16 1.88
20.0 15.0 2.79 2.58 2.37 2.16 1.88
MODEL : AU
 
G09LVLA
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.36 2.18 2.00 1.83 1.59
-10.0 -11.0 2.64 2.44 2.24 2.05 1.78
-5.0 -7.0 2.94 2.71 2.49 2.28 1.98
0.0 -2.0 3.21 2.96 2.72 2.49 2.17
5.0 3.0 3.44 3.18 2.92 2.67 2.32
7.0 6.0 3.52 3.25 2.99 2.73 2.38
10.0 8.0 3.52 3.25 2.99 2.73 2.38
15.0 10.0 3.52 3.25 2.99 2.73 2.38
20.0 15.0 3.52 3.25 2.99 2.73 2.38
MODEL : AU
 
G12LVLA, AU

G12LVLB
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3 .13 2.88 2.65 2.42 2.11
-10.0 -11.0 3.50 3.23 2.97 2.71 2.36
-5.0 -7.0 3.89 3.59 3.30 3.02 2.63
0.0 -2.0 4.25 3.92 3.61 3.29 2.87
5.0 3.0 4.56 4.21 3.87 3.53 3.08
7.0 6.0 4.66 4.30 3.96 3.62 3.15
10.0 8.0 4.66 4.30 3.96 3.62 3.15
15.0 10.0 4.66 4.30 3.96 3.62 3.15
20.0 15.0 4.66 4.30 3.96 3.62 3.15
MODEL : AU
 
G14LVLA, AU

G14LVLB
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.79 3.50 3.22 2.94 2.56
-10.0 -11.0 4.24 3.91 3.60 3.29 2.86
-5.0 -7.0 4.72 4.35 4.00 3.65 3.18
0.0 -2.0 5.15 4.75 4.37 3.99 3.48
5.0 3.0 5.52 5.10 4.69 4.28 3.73
7.0 6.0 5.65 5.22 4.80 4.38 3.82
10.0 8.0 5.65 5.22 4.80 4.38 3.82
15.0 10.0 5.65 5.22 4.80 4.38 3.82
20.0 15.0 5.65 5.22 4.80 4.38 3.82
HEATING CAPACITY
TC : Total Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 28) -
