2-5. Wall mounted type
Model name ASYG07KGTB ASYG09KGTB ASYG12KGTB ASYG14KGTB
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.29
Fan
Airflow rate
Cooling
HIGH
m
3
/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 270 270 270 280
Heating
HIGH 720 750 770 800
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 30 49
Sound pressure level*
1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level
Cooling
dB (A)
54 55 56 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D) mm
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch mm
Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages
Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
270 × 834 × 215
Gross 277 × 914 × 332
Weight
Net
kg
10.0
Gross 12.5 13.0
Connection pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose
Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type
Wireless (Option: Wired, Mobile app*
2
[FGLair
™
])
NOTES:
• The protective function might work when using it outside the operation range.
• *
1
: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *
2
: Available on Google Play
™
store or on App Store
®
. Optional WLAN Adapter is also required. For details, refer to the setting manual.
- 19 -
2-5. Wall mounted type
2. Specifications
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu AUXG14KVLA Specifications

General

Brand	Fujitsu
Model	AUXG14KVLA
Category	Air Conditioner
Language	English
