Fujitsu AUXG14KVLA Design & Technical Manual

6-2. Cooling capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOYG30KBTA4
Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
49
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
48
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
47
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
46
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
45
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
44
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
43
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
- 394 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4
