Getting started
Connecting the device
Please observe th e safety information in "I mport ant notes", Page 7.
CE conformance and optimum picture quality are guaranteed only if
you use the data cables supplied.
► Switch off the monitor and the computer.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The data cables supplie
d have two 15-p in D -SUB connectors or two 24-pin DVI
connectors for connect
ion to the monitor and to the computer.
Informationonthecom
puter connections an d interfaces is contained in the
operating m anual for
the compute r.
2
5
67
9
4
8
3
1
9
1=Securi
ty slot for Security Lock
2 = Power connector
3=AUDIO
-IN socket
4 = D isplayPort socket
5=DVI-D
socket (DVI)
6=D-SUBs
ocket (VGA)
7 = AUDIO-OUT soc k et
8=USBIN
(Downstream)
9 = USB O UT (Upstream)
► Select the appropriate data cable for your co mputer.
