Interfaces and c onnectors English -
3
Brief description of mainboar
d
Information about boards
Be sure to observe the following f or boards with ESD:
• You must always discharge static build up (e.g. by touching a grounded object)
before working with the board.
• The equipment and tools you use must be free of static charge.
• Remove the power plug from the mains supply before inserting or removing
boards.
• Always hold boards by their edges.
• Never touch connector pins or conductors on the board.
An overview of the features is provided in the data sheet.
Special features
Your mainboard is available in different configuration levels. Depending on the con figuration,
your mainboard will be equipped with or provide s uppo rt for c ertain features.
This manual describes the most important properties of this mainboard.
Additional information on mainboards is provided in the manual "Basic information on m ainboard"
on the "U ser Documentation" or "OEM Mainboard" CD, or on the Internet.
Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the beginning of the manual.
The componen ts and connectors marked are not necessarily presen t on the mainboard.
External ports
The location of the external connections of your mainboard is specified at the beginning of the manual.
PS/2 keyboard po rt, purple PS/2 mouse port, green
LAN port (RJ-45)
Microphone jack, pink
Audio input (Line in), light blue USB – Universal Serial Bus, black
Audio output (Line out), light green VGA, blue
Serial interface, turquoise
In accordance with the U
SB 2.0 specification, the e xternal USB ports must
only be loaded with a max
imum of 500 mA per USB port.
Fujitsu Technology Solutions 21
