Fujitsu D3162-B User Manual

a
g
e
2
Page
TechNotes D3162-B V1.0 Page 2 of 45 www.ts.fujitsu.com/mainboards
Content
1 Safety Instructions 4
2 Feature Overview D3162-B 5
2.1 Basic Layout 8
2.2 Block Diagram 9
2.3 External Connectors D3162-B 10
2.4 Onboard components D3162-B 11
2.5 I/O-Shield 12
3 Interfaces & Connectors 14
3.1 Frontpanel Connector 14
3.2 Internal Parallel Port Connector 15
3.3 Internal USB2.0 Connector (2 x 2 Ports) 15
3.4 Internal USB3.0 Connector (1 x 2 Ports) 16
3.5 External USB3.0 Connector 16
3.6 Fan Connector 17
3.7 Power Supply Fan Connector 17
3.8 High Definition Frontpanel Audio Connector (HD Audio) 18
3.9 AC97 Frontpanel Audio Connector (Legacy Audio) 18
3.10 Power Supply Connector 19
3.11 Additional Power Supply Connector 19
3.12 Chassis Intrusion 20
4 System Monitoring 21
4.1 D3162-B: Temperature Sensors and Fan Connectors 22
4.2 D3162-B: SystemGuard 23
4.3 D3162-B: SystemGuard - Details 24
4.4 SilentFanConfigManager – Customize System Monitoring Settings 25
4.5 Components for continous 24/7 operation @ +45°C 26
4.6 Capacitor Endurance Time Comparison 27
4.7 Temperature Reference Points D3162-B 28

Fujitsu D3162-B Specifications

General

Brand	Fujitsu
Model	D3162-B
Category	Motherboard
Language	English
