D3162-B
V1.0
Page
32
of
45
www.ts.fujitsu.com/mainboards
Displa
y
Op
t
ions
6.3
HDMI Output
max. HDMI screen r
esolution:
1920 x 1200
HDMI transfers Vide
o & Au
dio
Digital (HDMI) Monitor
Note: H
DMI Audio De
vice needs to
be
enabled via Co
ntrol Pane
l!
HDMI
DVI
-HDMI Interface
Connect
or
31
33
