18 – English
Mainboard D3488
Power Supply Considerations
Power Connectors
The D3488 is operated with a 12 V power supply.
12 V Power Connectors
Pin 1
Pin 9
Pin 1
Pin 7
16-pin board power connector
12-pin board power connector
Pin 1
Pin 5
8-pin connector to
supply the drives
56
