Getting started
► Connect a connector of the data cable to the D-SUB socket or HDMI socket or to the DP socket
of the monitor. Secure the plug-in connection by tightening the safety screws when available.
The m on itor automatically detects the input when only one signal source is conne cted .
► If analogue audio will be o utput on the m onitor, plug a connector of the audio cable (not in the
delivery scope) into the AUDIO IN socket on t he monitor and make sure that it engages securely.
► Plug the power cable supplied into the pow er connector o f the monitor.
► Plug the s upplied USB cable into the USB IN socket and the other end of
the cable into a USB socket of the computer.
A lock (Security Lock) can be mounted in the security slot to protect the monitor
against t heft. A Security Lock is not included with the monitor at delivery.
Connecting cables to the computer
Information on the compu ter connections and interfaces is contained in the
operating manual for your computer.
► Connect the data cable to the (active) monitor port on the computer and secure t he
plug-in c onnection by tightening the safety screws when availab le.
► If used, insert the other plug of the aud io cable into the audio output of the computer.
► Plug t he power connector of the monitor into a properly grounded mains outlet.
► Plug the power connector of the computer into a p rope rly grounded mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the m onitor port for the s eparate graph ics card is active as sta ndard.
Fujitsu 17
