6.2ErrorIndicationsintheOperatorPanel(1)
fi-5120C / fi-5220C Image Scanner Operator Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP

6.2ErrorIndicationsintheOperatorPanel(1)


1
2
When any error occurrs, the operator panel indicates "U" followed by a number for temporary errors or "E" followed by a
number for device alarms (permanent error). Temporary errors can be resolved by the operator, but the device alarm requires
recovery works by support engineers.
When the Error Recovery Guide is installed on your PC, its window appears when Windows is started up. If any error or device
alarm occurred, this software displays information such as error names and error codes regarding the error/alarm. Record the
information and click [Details] on its window to learn detailed information for trouble shooting.
Temporary Errors :
Indication Meaning Remedy
U0
Shipping lock error(fi-5220C
only)
Confirm that the shipping lock is released. For details refer toA[fi-5120C/fi-
5220C Getting Start section 2.1 Installing the Scanner].
U1 Paper Feed Error
Remove the jammed documents. Refer to "
6.1 Removing
JammedDocuments".
Confirm that the documents meet the paper conditions for scanning. Refer
to "
7.2 Document Quality".
U2 Multi Feed Error
U4
The ADF has been opened
during scanning.
Close the ADF cover completely. For the details, refer to "6
TROUBLESHOOTING".
U6
The print cartridge is not set.(fi-
5120C only)
This is a temporary error related withthe Imprinter option (sold separately).
For details refer to 553PR Operator's Guide, chapter "5 Error Message".
HINT
The Error Recover Guide is stored in Setup CD-ROM. When installing the application
software, refer to "2.1 Installing the Scanner Application" in fi-5120C/fi-5220C Getting
Started.


1
2

AllRightsReservedCopyright2006©PFULIMITED
file://///Hd-htgle21/Manual/fi-5120C5220C-lynx2/OG/R03/contents/EN/06/c060201.htm2006/08/2916:01:30

Fujitsu fi-5220C Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	2 sec/page
Scanner type	Flatbed & ADF scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	SCSI, USB 2.0
Bundled software	-FJ TWAIN driver. -Scandall. -Adobe Acrobat. -ISIS Driver. -QuickScan (demo). -Soft IPC (demo). -VRS 4.1 Basic.
Dimensions (WxDxH)	302 x 569 x 229 mm
Power requirements	100-240 VAC
Power consumption (standby)	6 W
Power consumption (typical)	34 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Weight	8400 g
