6.3RemedyingTypicalTroubles
fi-5120C / fi-5220C Image Scanner Operator Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP

6.3RemedyingTypicalTroubles


Symptom: Images are distorted or blurred.
Back
Are the upper/lower glasses inside the ADF, the
document bed, and the document holding pad clean?
NO
Clean dirty locations. (*)
YES
Is the ADF cover pressed down or heavy object
placed on the ADF during scanning?
YES
Do not press down the ADF or place heavy object on
the ADF during scanning.
NO
Is something causing the scanner to vibrate during
scanning?
YES
Do not allow anything to cause the scanner to
vibrate while scanning.
NO
Is the scanner installed on a flat, level surface?
NO
Install the scanner on a flat, level surface.
YES
If you cannot solve the problem after taking
measures, check the items in "6.4 Items to check
before contacting the dealer where you bought the
scanner" and contact the dealer or an authorized
FUJITSU scanner service provider.
*)For details on how to clean dirty locations, see "
Chapter 4 DAILY CARE".
AllRightsReservedCopyright2006©PFULIMITED
file://///Hd-htgle21/Manual/fi-5120C5220C-lynx2/OG/R03/contents/EN/06/c0603/06.htm2006/08/2916:01:46
