6.3RemedyingTypicalTroubles
fi-5120C / fi-5220C Image Scanner Operator Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP

6.3RemedyingTypicalTroubles


Symptom: Pickup errors occurs frequently.
Back
Do the documents satisfy the conditions
described on "7.2 Document Quality"?
NO
Use documents that satisfy the quirements.
(*1)
YES
Were the documents fanned before loading on
ADF paper chute?
NO
Fan the document before loading, or reduce
the number of sheets of the documents.
YES
Are all the consumables (Pick roller and Pad
ASSY) installed correctly?
NO
Correctly install the consumable(Pick roller and
Pad ASSY), if needed. (*2)
YES
Is any of consumables (Pick roller, Pad ASSY)
dirty?
YES
Clean the dirty consumable. (*3)
NO
Is any of consumables (Pick roller and Pad
ASSY) worn out? (Check the consumable
counter)
YES
Replace the consumable, if needed. (*4)
NO
If you cannot solve the problem after taking
measures, check the items in "6.4 Items to
check before contacting the dealer where you
bought the scanner" and contact the dealer or
an authorized FUJITSU scanner service
provider.
file://///Hd-htgle21/Manual/fi-5120C5220C-lynx2/OG/R03/contents/EN/06/c0603/10.htm(1/2)2006/08/2916:01:40

Fujitsu fi-5220C Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	2 sec/page
Scanner type	Flatbed & ADF scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	SCSI, USB 2.0
Bundled software	-FJ TWAIN driver. -Scandall. -Adobe Acrobat. -ISIS Driver. -QuickScan (demo). -Soft IPC (demo). -VRS 4.1 Basic.
Dimensions (WxDxH)	302 x 569 x 229 mm
Power requirements	100-240 VAC
Power consumption (standby)	6 W
Power consumption (typical)	34 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Weight	8400 g
