4.2 Installation Specifications
fi-60F Image Scanner Operator’s Guide 39
SCANNER SPECIFICATION
4
4.2 Installation Specifications
Item Specification
Dimensions (mm)
(just the scanner, docu-
ment cover closed)
Depth Width Height
234 (9.21 in) 145 (5.71 in) 40 (1.58 in)
Installation Space (mm)
Depth Width Height
281 (11.06 in) 145 (5.71 in) 257 (10.12 in)
Weight (kg) 0.9 (2 lbs)
Input
power
Voltage 100 to 120 VAC ±10%
220 to 240 VAC ±10%
Phases Single-phase
Frequency 50 / 60 ± 3Hz
Power consumption Operating : 8W
Stand by: 2W
Low Power Mode: 1W
Installation Space is the reference value of an installation space
required for opening and closing the document cover.
Item Specification
Ambient
condition
Device status Operating Not operating
Temperature 5 to 35 °C (42 to 95°F) -20 to 60 °C (-4 to 140°F)
Humidity 20 to 80 %
(no condensation)
8 to 95 %
Heat capacity 6.1 kcal/h
Shipping Weight (kg) 2.0 (4.41 lbs)
