2.2 Server node specification
This section explains the specifications for the server node. The specifications
for this server node are liable to be updated without any notice. Please be
forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3343
Chipset Intel
®
C610
Processor quantity and
type
2 x Intel
®
Xeon
®
processor E5-2600v3 product
family
Memory slots 16 (4 channels per CPU with 8 DIMMs per CPU = 16
DIMM in total)
Memory slot type DDR4
Memory capacity
(min. - max.)
16 GB - 1024 GB
Memory protection Advanced ECC; SDDC (Chipkill™)
Memory notes Supports LV-R-DIMM, LV-LR-DIMM
USB connectors 2 x USB 3.0
Graphics (15-pin) 1 x VGA
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet + 1 x 100Mbit Management LAN
onboard
Management LAN
(RJ45)
Management LAN traffic can be switched to shared
onboard Gbit LAN port
