TX100 S1 Options Guide 27
6 Accessible drives
V CAUTION!
Follow the safety instructions in the chapter "Safety instructions" on
page 11.
Two 5.25-inch bays are available for accessible drives. DVD drives or magnetic
tape drives can be installed in these slots.
By default, the upper slot is fitted with a DVD drive.
6.1 Preparation
Ê Open the server (see section "Opening the server" on page 17).
Ê Remove the dummy cover and the sheet metal plate (TX100S1-2HDD) or
the dummy module (TX100S1-4HDD).
Removing the dummy cover and the sheet metal plate (TX100S1-2HDD)
Figure 10: Removing the dummy cover
Ê Remove the dummy cover.
