Fujitsu ScanSnap S1500 User Manual

Installing in Windows
52
■ Trial software
The procedure is as follows.
1. Turn on the computer and log on as a user with Administrator privileges.
2. Insert the Setup DVD-ROM into the DVD-ROM drive.
D The [ScanSnap Setup] dialog box appears.
3. Click the [Trial Software] button.
Example: [ScanSnap Setup] dialog box for S1300i
D The [Trial Software] dialog box appears.
HINT
For details about system requirements and installation, refer to "Readme" of the trial version software.
Click on the name of the software in the [Trial Software] dialog box, then click the [Readme] button to open
the Readme file.
HINT
If the [ScanSnap Setup] dialog box does not appear, double-click "ScanSnap.exe" in the Setup
DVD-ROM via Windows Explorer.

Fujitsu ScanSnap S1500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	ScanSnap Organizer V4.0, CardMinder V4.0, Adobe Acrobat 9 Standard, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
