1.10 Simulation Display
The simulation display, for use by service technicians for demonstration purposes, provides
simulated operation to help acquaint you with the many features your unit has to offer. It
allows you to view and control a simulated plotter, radar and sounder picture, without
position-fixing equipment, network radar or a network sounder. Most controls are operative,
thus you may practice setting destination, enter waypoints, measure range and bearing to a
target, etc. Three simulation displays are provided for both the radar and echo sounder.
The simulation icon (SIM) appears when any simulation mode is active.
To start the simulation display;
1. Press the MENU key.
2. Press the SYSTEM CONFIGURATION, SYSTEM SETUP and SIMULATION SETUP
soft keys in that order.
SIM
SETUP
EDIT
RETURN
RADAR LIVE
PLOTTER LIVE
SOUNDER LIVE
SPEED 00.0kt
COURSE 000.0
°
LATITUDE 45 ° 35.000'N
LONGITUDE 125
° 00.000'W
START DATE & TIME 00:00 01.APR.00
GET RADAR SIMULATION DATA NO
Simulation setup menu
3. Follow appropriate procedure on the next several pages. To stop the simulation mode
and return to normal operation, choose LIVE for radar, sounder or plotter.
Radar
NavNet display unit-generated echoes or user data
1. Select RADAR, then press the EDIT soft key.
RADAR
▲
¡ BUILT IN DATA 1
¡ BUILT IN DATA 2
¡ USER DATA
¤ LIVE
▼
2. Select BUILT IN DATA 1 or 2 for internally generated echoes or USER DATA for
user-saved radar data. Push the ENTER knob.
3. Press the MENU key to close the menu.
