SPECIFICATIONS OF THE NETWORK SOUNDER
DFF1
1. GENERAL
1.1. Output Power 600 W/ 1 kW rms nominal, 1 kW requires optional MB-1100
1.2. TX Frequency 50 kHz or 200 kHz, 50/200 kHz exchangeable
1.3. Amplifier type Wide dynamic linear amp (double superheterodyne)
1.4. Network protocol Ethernet 100/10BASE-TX
1.5. Depth Range and Pulse Repetition Rate
2. POWER SUPPLY
12-24 VDC: 1.1-0.4 A (at 1 kW output)
3. ENVIRONMENTAL CONDITION
3.1. Ambient Temperature -15°C to +55°C
3.2. Relative Humidity 93% at 40°C
3.3. Dustproofing, waterproofing IP20 (not waterproof)
(IEC60529)
3.4. Vibration (IEC 60945 Ed4)
- 2-5 Hz and up to 13.2 Hz with an excursion of ±1 mm ±10 %
(7 m/s
2
maximum acceleration at 13.2 Hz)
- 13.2-100 Hz with a constant maximum acceleration of 7 m/s
2
4. COATING COLOR
4.1. Main Unit N3.0
Range (m) PRR ( /min.)
2 3000
5 3000
10 1990
40 485
100 195
200 95
400 65
1200 34

Furuno DFF1 Specifications

General

Brand	Furuno
Model	DFF1
Category	Marine Equipment
Language	English
