1
1. MOUNTING
1.1 Equipment Lists
Standard supply
Optional supply
Note: Use only 600 W/1 kW transducer. Use of other types will damage the transducer.
Name Type Code No. Qty Remarks
Network Sounder DFF1 - 1
Spare Parts SP02-05201 001-007-860 1 set Fuse
Installation Materials CP02-08100 000-010-153 1 set Power cable, LAN cable,
Self-tapping screws
Name Type Code No. Remarks
Matching Box MB-1100 000-041-353 For 1 kW
Cable Assy. MJ-A6SPF0017-010C 000-159-704-11 1 m, for NavNet
MJ-A6SPF0017-100C 000-159-706-11 10 m, for NavNet
MJ-A6SPF0017-200C 000-159-707-11 20 m, for NavNet
MJ-A6SPF0017-300C 000-159-708-11 30 m, for NavNet
MJ-A6SRMD/TM11AP8-005 000-144-463 For HUB
MOD-Z072-020+ 000-167-175-10 2 m, HUB-101
MOD-Z072-100+ 000-167-177-10 10 m, HUB-101
Inner Hull Kit S 22S0191-2 000-802-598
Triducer 525STID-MSD 000-011-783 Thru-hull mount, metallic
525STID-PWD 000-011-784 Transom mount, plastic
Transducer 520-5PSD 000-015-204 Thru-hull mount, plastic
520-5PWD 000-015-126 Transom mount, plastic
520-5MSD 000-015-212 Thru-hull mount, metallic
50B-6 000-015-042 10 m, 1 kW
50B-6B 000-015-043 15 m, 1 kW
50B-9B 000-015-065 15 m, 1 kW
200B-5 000-015-027 10 m, 1 kW
200B-5S 000-015-029 10 m, 1 kW
50/200-1T 000-015-170 10 m, 1 kW
50/200-12M 000-015-171 10 m
Speed/Tempera-
ture Sensor
ST-02MSB 000-137-986 Thru-hull mount, metallic
ST-02PSB 000-137-987 Thru-hull mount, plastic
Temperature
Sensor
T-02MTB 000-040-026 Transom mount
T-02MSB 000-040-040 Thru-hull mount
T-03MSB 000-040-027
Cable Assy. 02S4147 000-141-082 For Speed/Temp sensor,
Temp. s e n s o r
Rectifier PR-62 000-013-484 100 VAC
000-013-485 110 VAC
000-013-486 220 VAC
000-013-487 230 VAC
