9. INSTALLATION
9-8
9.5 Language Setting
When you first turn the power on after installation, you are asked the language to use
on the equipment. Press S or T to select the language, and press the ENT key.
9.6 Input/Output Data
This equipment inputs/outputs NMEA0183 or CAN bus data shown below. Note that
NMEA 0183 version (2.0 or 3.0) can be a selected from the I/O setup screen.
Data 1: CAN bus port (input)
PGN Description Remark
059904 ISO Request
060928 ISO Address Claim
061184 #4=0 Self Test Group Function
065286 Proprietary; Boot State Request
126208 Request Group Function
Command Group Function
126720 #4=1 Memory Clear Group Function
126720 #4=2 Reset Group Function
To Next Page
