Furuno TZT12F User Manual

13
ACCU-FISH
TM
/Bottom Discrimination/RezBoost
TM
Zoom display
Search for bottom
fish.
Find bottom contour
and hardness.
Short tail: Soft bottom
Long tail: Hard bottom
Tap
ON
ON
Raise the echo resolution (requires RezBoost
TM
capable transducer).
(Standard mode)
(High resolution mode)
RezBoost
TM
ON
Fish size or depth
Fish symbol
NoticeNotice
You can select fish symbol type, and fish size or depth indication from the menu - go to home screen, [Settings], [Sounder].
ACCU-FISH
TM
Detected fish can be marked with a fish symbol (requires ACCU-FISH
TM
capable transducer).
Show probable bottom hardness
(requires bottom discrimination capable transducer).
Bottom Discrimination
ON
Bottom
discrimination
display
The most probable bottom material.
Rock
Gravel
Sand
Mud
Bottom
ホーム
m
LF/HF
576
50/200 kHz
m
BL/HF
20.5
200 kHz
m
BZ/HF
20.5
200 kHz
Show the layer menu.
