Plotter
Swipe from the left edge of the screen rightward to show the data area at the left edge of the screen.
Tap “<” to hide the data area.
Data Area (Data Box)
Display range
Data area
Inactive route
(expanded)
Point
Track
COG vector (broken line)
Return own
ship to screen
center
Tap
Orientation Mode
Switch between
NU and HU.
Switch between 2D
and 3D. (Drag upward
with two fingers also.)
2D:
3D
3D:
3D
Boat icon
Inactive route
(sleeping)
(Departure or
arrival point,
selectable on
[Layers] menu.)
DATA ROUTE RADAR
DATA ROUTE RADAR
Heading line
(yellowish-green solid line)
How to add a data box
How to remove or change the contents of a data box
How to remove or change the contents of a data box
Tap the data to add.
Tap an unoccupied space.
Ex. “Cursor” data added to the data
box
Tap the data to remove or change.
Tap the data to remove or change.Tap the data to remove or change.
Data box settings
Remove: Tap [Remove].
Change: Tap the data to use.
Use flipswitch to set data format.
(ON: Analog, OFF: Digital)
DATA ROUTE RADAR
DATA ROUTE RADAR
DATA ROUTE RADAR
