9. Cutting test:
Place a strip of paper
S
in such a way on the lower blade
P
that it points towards the spindle of the cylinder
O
.
10. Turn cylinder
O
carefully.
If the lower blade is set correctly
P
the paper will be cut off as if with scissors.
11. Repeat the cutting test on the other blades
O
.
On safety grounds, only original GARDENA spares
A
may be used.
Please contact GARDENA Service if it is necessary to replace
the cutting tool, which will only become blunt after several years
use if well-maintained.
Have the cylinder mower checked over in the autumn if possible
so that it is ready for use immediately when the next lawn-mowing
season starts.
A
In the event of other faults please contact GARDENA Service.
Repairs should only be carried out by GARDENA service centres or dealers
authorised by GARDENA.
10. Accessories
GARDENA The long-lasting, reliable power source Art. No. 8838
Replacement Battery for increased cutting capacity, ideal for
Li-Ion 25 V larger lawns of more than 400 m².
11. Technical Data
Type 380 Li (Art. 4025)
Cutting width / Cutting height 38 cm / 12 - 42 mm
Cutting height adjustment infinitely variable
Weight with Accu 13.6 kg
Accu Voltage / capacity 25.2 V/ 3.2 Ah
Lawn area per Accu-charge Up to 400 m
2
(see 4. Function)
Working area related emission
characteristic value L
pA
1)
70 dB (A)
Noise level L
WA
2)
measured 85 dB (A) / guaranteed 86 dB (A)
Vibrations a
vhw
1)
< 2.5 m/s
2
Measuring method
1)
according to EN 836
2)
according to RL 2000/14/EG
Repairs:
O
S
P

Gardena 380 LI Specifications

General

Type	Push lawn mower
Cutting width	380 mm
Cutting height	42 mm
Cutting system	Cylinder blades
Ergonomic handle	Yes
Recommended lawn area	400 m²
Minimum cutting height	12 mm
Grass collecting volume	- L
Power source	Battery
Battery voltage	25 V
Battery capacity	3.2 Ah

Weight and Dimensions

Weight	14000 g
