109
SECTION
7
UNIT SETTINGS
SUA Settings
Altitude Buffer
The Special Use Airspace settings page will allow you to turn the controlled/
restricted airspace message alerts on or off. This will not affect the alerts listed on the
nearest page. It will simply turn off the warning when you are approaching or near an
SUA. Warnings can be turned on/off for the following airspaces:
class B/cta : ICAO control area moa: Military operations area
class C/tma : ICAO Terminal Control Area other: Other areas includes- alert,
rstcd: Restricted areas caution, danger, training, warning
SUA warnings for prohibited airspace cannot be turned off. The ‘alt’ field,
located at the bottom of the SUA settings page, is an altitude buffer which ‘expands’ the
vertical range of the SUA, so you will be notified if you are within a certain range of an
SUA. For example, if the buffer is set at 500 feet, and you are more than 500 feet above
or below an SUA, you will not be notified with an alert message; if you are less than
500 feet above or below an SUA and projected to enter it, you will be notified with an
alert message. The default setting for the altitude buffer is 200 feet.
To set the warnings or change the altitude buffer:
1. Press and hold
M
, and use
O
to display the SUA settings page.
2. Press
C
twice.
3. Rotate
O
to highlight the field you would like to change.
4. Use
K
to change to ‘on’ or ‘off’.
5. To change the altitude buffer, highlight the buffer value, and use
K
and
O
to change the
data. Press
E
to accept.
6. Press
C
to complete.
The SUA settings page with ‘other’ airspaces dis-
abled and the altitude buffer set to 500 feet.
The SUA settings page with all airspace alerts
enabled and the altitude buffer set to 100 meters.
300xl manual 1/25/99 2:36 PM Page 109
