Garmin G1000 Airplane Flight Manual Supplement

MOONEY
M20R
AFM SUPPLEMENT
GARMIN G1000 INTEGRATED AVIONICS SYSTEM
ISSUED 11 - 2004
33 of 33
REVISION A 06 -- 2005
FAA APPROVEDREVISION B 03 -- 2006
7.4 -- INSTRUMENT PANEL
The instrument panel has been designed to incorporate the G1000 Inte-
grated Cockpit. All Communications, Navigation, Engine Instruments,
and System annunciations have been integrated into a custom design
package specifically for the M20R series aircraft.
Engine and electrical switches are located on the left side of the switch
panel. Nav, strobe, recognition / landing and taxi light switches are lo-
cated on the overhead switch panel.
Instrument panel lighting is provided by post lights, overhead panel
lights and the internally lighted G1000 Integrated Cockpit System. Opti-
mum cockpit panel lighting for night flying is achieved by using a com-
bination of panel lights and overhead map lights.
SECTION VIII – HANDLING AND SERVICING
No change.
SECTION IX – SUPPLEMENTAL DATA
Add this supplement to this Section.
SECTION X – SAFETY TIPS
No change.

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
