Garmin G1000 Airplane Flight Manual Supplement

MOONEY
M20R
AFM SUPPLEMENT
GARMIN G1000 INTEGRATED AVIONICS SYSTEM
ISSUED 11 - 2004
7of33
REVISION A 06 -- 2005
FAA APPROVEDREVISION B 03 -- 2006
SECTION II -- LIMITATIONS
GENERAL
G1000 System:
1. The GARMIN G1000 Cockpit Reference Guide for the M20R Series
aircraft, P/N 190--00450--01, Revision A or later approved revision
must be immediately available to the flight crew.
2. The GARMIN G1000 must utilize the following or later FAA approved
software versions:
SUB--SYSTEM
SOFTWARE VERSION
PFD 4.06
MFD 4.06
GMA 2.08
AHRS 2.03
ADC 2.05
GIA 2.08
GEA 2.04
GPS 3.01
The database version is displayed on the MFD power--up page immedi-
ately after system power--up and must be acknowledged. The remain-
ing system software versions can be verified on the AUX group sub--
page 5, “AUX – SYSTEM STATUS”.
3. IFR enroute, oceanic and terminal navigation predicated upon the
G1000 GPS Receiver is prohibited unless the pilot verifies the cur-
rency of the database or verifies each selected waypoint for accura-
cy by reference to current approved data.

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
