GMC 7XX Installation Manual Page 2-1
190-00303-70 Revision F
2 INSTALLATION OVERVIEW
2.1 Introduction
This section provides hardware equipment information for installing the GMC 7XX and related hardware.
Installation of the GMC 7XX should follow the aircraft TC or STC requirements. Cabling is fabricated
by the installing agency to fit each particular aircraft. The guidance of FAA advisory circulars AC 43.13-
1B and AC 43.13-2A, where applicable, may be found useful for making retro-fit installations that
comply with FAA regulations. Refer to the G1000 System Installation Manual, Garmin part number
190-00303-00 for further details on the mechanical aspects.
2.2 Installation Materials
The GMC 7XX is available as a single unit under the following part number:
Item Catalog P/N
GMC 705 Unit Only, (011-01737-00) 010-00663-00
GMC 705 w/YD Unit Only (011-01737-20) 010-00663-20
GMC 710 Unit Only, (011-01020-00) 010-00347-00
GMC 710 Unit Only, (011-01020-10)* 010-00347-10*
GMC 715 Unit Only, (011-01430-00) 010-00554-00
* Garmin recommends this GMC 710 for new TC/STC approvals. Garmin does not recommend the use
of 011-01020-00 for new TC/STC approvals. Unit maintains the same form, fit, and function as the
original GMC 710.
2.2.1 Equipment Available
Each of the following accessories are provided separately from the GMC 7XX LRU. A single connector
kit and mounting hardware is required to install the unit.
Item Garmin P/N
GDU Mounting Hardware, panel thickness 0.080” ± 0.005
011-00821-00
GDU Mounting Hardware, panel thickness 0.125” ± 0.005
011-00821-01
GDU Mounting Hardware, panel thickness 0.090” ± 0.005
011-00821-02
GDU Mounting Hardware, panel thickness 0.100” ± 0.005
011-00821-03
GMC 71X Connector Kit (GMC 710 and 715) 011-01040-01
Connector Kit (GMC 705) 011-01824-00
2.3 Installation Considerations
The GMC 7XX interfaces with the GFC 700 AFCS (which consists of the GDU 1XXX, GIA 63(W),
GSA 80/81, and the GSM 85 LRUs) and with various avionics equipment. Fabrication of a wiring
harness is required. Sound mechanical and electrical methods and practices are required for installation
of the GMC 7XX.
