31-5000483 Rev. 2 15
Installation of Drain Pipe
Sealed
Saddle
Drain
Pipe
Bundle the line set, drain, and wiring.
If penetrating concrete or brick, a wall sleeve should be
used.
Be sure to seal both inside and outside wall penetrations.
Wind insulating tape around the entire bundle from the
bottom up.
Be sure the drain does not terminate in standing water.
Provide adequate support for the entire bundle per local
code.
Installation Instructions
