33
The 'Turn and Push' (T & P) switch is used to:
• Fill the hot water tank if it is not full such as when unit is first
installed.
• Dispense the hot water once it is heated and ready to dispense.
• Purge the water tank during the Purge Mode if the water
temperature in the tank is higher than the consumer desired
water temperature.
NOTE: The consumer must continuously hold the T & P switch for
the above operations to happen.
The RED LED around the 'Turn and Push' (T & P)
switch is either turned off, turned on solid or
pulsed depending on the hot water operation
mode. BLUE LED is on during any hot water
operation
Hot Water Dispenser
Turn and Push
(T & P) switch
To Next Page
