GE DCVH515 Service Manual

– 15 –
After reversing the door, there will be a mismatch
between the door cover and door frame.
Make sure that the handle part of the door cover is
opposite the hinge as shown.
Turn the door over. Install the 6 (#10) tapping
screws that attach the door cover to the door
frame.
19.
Using a putty knife or fl at tool, remove the
5 plastic screw caps located near the strike
bracket on the front panel. Install the caps on
the opposite side.
20.IMPORTANT: Make sure there is no dirt or any other
foreign material in between the window panes.
Place the door cover onto the door frame. 18.
Outer
Door
Inner
Door
Top of Door
Top of Door
Door
Frame
Door
Cover
Remove the 4 Philllips-head screws that attach
the strike bracket and cover to the front panel.
Reinstall both on the opposite side.
21.
Note: To ease installation of the door, the hinge has
a keyhole that allows a partially fastened screw to
be used as a hook.
Partially fasten a Phillips-head screw to the
uppermost screw hole. Hook the door on the
partially fastened screw.
Fasten the hinge by installing the remaining 4
Phillips-head screws and tightening the partially
fastened top screw.
22.
23.
Partially
Inserted Screw
Tighten All
Screws
Plug the dryer into its electrical outlet.24.
