– 12 –
Reversing the Door Swing
When viewed from the front, the dryer is shipped
so the door opens from the left. Due to utility
confi gurations or customer preferences, the door
can be set up to open from the right by reversing
the door swing.
Note: These instructions are for changing the dryer
so the door opens from the right side. To change the
door back so that it opens from the left side, follow
these same instructions and reverse all references
to left and right.
Note: To ease removal of the door, the hinge has a
keyhole that allows a partially loosened screw to be
used as a hook.
Loosen the top Phillips-head screw, then lift and
unhook the door from the front panel. Remove
the top screw.
3.
To reverse the door swing:
Unplug the dryer from its electrical outlet.
Open the door to approximately 90 degrees.
Starting from the bottom to the top, remove the
bottom 4 Phillips-head screws from the hinge.
Note: Make sure the door is supported while
removing the screws.
1.
2.
Phillips Head
Screwdriver
Putty Knife or Thin-
Blade Screwdriver
Tools Needed
Hinge
Assembly
Hinge
Cover
Window
Retainer
Large Tapping
Screw (#10) – 6
Tapping
Screw (#8) – 2
Machine
Screw (#8) – 6
Door Parts
Lay the door on a soft protected fl at surface so
that the inside faces upward (door resting on the
handle side).
4.
(Continued Next Page)
