DE GT Series: User manual rev date 8-11-04
Digital Energy GT Serie
GT Model
1000T UL 1500T UL 2000T UL 3000T UL
Capacity 1kVA/800W
1.5kVA/ 1200 W
2kVA/1600W
3kVA/2400W
Rated Voltage 100V, 110V, 120V
Voltage Range 80V~138V (full load); 65V~80V (70% load)
Frequency 50Hz / 60Hz (± 4.8 Hz)
Input
Power Factor 0.97
Voltage 100V, 110V, 120V
Frequency 50Hz / 60Hz
Voltage Regulation ± 2%
Frequency Accuracy ± 0.05 Hz
Wave Form pure sine wave
Transient Response ± 8% (10%90% linear load)
THD (linear load) 3% 3% 4%
THD (computer load) 6%
Overload Capacity 105%~125% for 3mins; 125%~150% for 30secs; >150% for 1sec
Crest Factor 3:1
Output
Efficiency (AC-AC) 87%
Outlet
Receptacles NEMA TYPE
Battery Voltage 36V 72V 72V
Battery Type (Lead acid) 12V/7Ah 12V/7Ah 12V/9Ah
Back-up Time
(Typical)
5mins
Battery
Recharge Time 4~6 hours after complete discharge to recover 90%
Transfer
Time
Transfer Time zero
LED Status
On-line / Bypass / On-battery / Overload / Battery Low / Fault
Battery Replace / Battery Level / Load Level
LED
Alarm buzzer
DB9 RS232/dry contact
Interface
SNMP Slot internal
Noise (At 1 Meter) 40dB(A) 42dB(A) 45dB(A)
Operating
Temperature
0~40°C (32~104°F)
Environment
Humidity 0%~90% (non-condensing)
Safety UL/cUL
EMC
FCC Class A (2, 3kVA) /B (1kVA)
CISPR PUB 22 Class B; TUV/EMC; CE (1kVA)
CISPR PUB 22 Class A (2, 3kVA)
Safety
Approval
Lightning IEEE 62.41 Category A
Battery Start yes
Extended Battery
Bank
yes (optional for longer runtime)
Others
Long Time Model yes (optional)
Dimensions
(W×D×H)
140x366x242 mm
5.5x14.4x9.5 inch
140x425x373mm
5.5x16.7x14.7 inch
Appearance
Weight
15 kg
33 lbs
30 kg
66 lbs
30 kg
66 lbs
8 - Specifications
