GE DISPOSALL GFC1020N User Manual

49-5903-3 9
INSTALLATION INSTRUCTIONS
Installation Instructions
DISHWASHER CONNECTION (IF REQUIRED)
ATTACH THE DISCHARGE ELBOW
1
KNOCK OUT PLUG
8VLQJDEOXQWLQVWUXPHQWVWHHOSXQFKRUZRRGHQ
GRZHONQRFNRXWWKHHQWLUHSOXJ'RQRWXVHD
screwdriver or sharp instrument. When knockout
plug falls into disposer, you may remove it or
simply grind it up when
the disposer is used.
7KLVZLOOQRWGDPDJH
the disposer in any
way, but may take
some time to grind,
over the course of
several uses.
1
ATTACH RUBBER GASKET
Slide rubber gasket over drain pipe.
2
CONNECT HOSE
Connect the dishwasher hose using a hose
clamp. If the hose size is different, you will need
a stepped rubber adapter.
2
CONNECT DISCHARGE
ELBOW*
Slide bracket over discharge elbow and connect
to the disposer.** Make sure all plumbing
connections are tight.
If you are connecting to a dishwasher, complete the
following step. If a dishwasher is not to be connected,
JRWR³$WWDFKLQJWKH'LVFKDUJH(OERZ´EHORZ
'LVFKDUJHHOERZPXVWEHLQVWDOOHGE\DSURIHVVLRQDO
** Some installations (see page 11 for example) may
require the use of a flexible drain pipe.
Knock out
plug
Hose Clamp
Stepped Rubber Adapter
Rubber
Gasket
Rubber
Gasket
'LVFKDUJH
Elbow
'LVFKDUJH
Elbow
